- Size: 48 cubic meter
- Place of Origin: Qingdao, Shandong province
- Brand Name: Super Herdsman
- Model Number: QDSH-001
- Weight: 8000.000 kg
1. Main feeding line system
In the main feeding line system the feed is transferred from the silo to the hopper in chicken house by auger. There is a feed sensor at the end of the main feed line which control of open and close of the motor to realize the automatic feeding.
Silo Model | Volume | Number of Layers | Height (exclusive of foundation) | Material |
QDSHS-01 | 4.4 m3, 2.8T | 1 | 4.1 m | Galvanized sheet |
QDSHS-02 | 6.8 m3, 4.4T | 2 | 5 m | Galvanized sheet |
QDSHS-03 | 9.2 m3, 5.9T | 3 | 5.9 m | Galvanized sheet |
QDSHS-04 | 11.7 m3, 7T | 1 | 4.7 m | Galvanized sheet |
QDSHS-05 | 16.9 m3, 10T | 2 | 5.6 m | Galvanized sheet |
QDSHS-06 | 22.1 m3, 13T | 3 | 6.5 m | Galvanized sheet |
QDSHS-07 | 24.5 m3, 16T | 1 | 5.8 m | Galvanized sheet |
QDSHS-08 | 34 m3, 22T | 2 | 6.7 m | Galvanized sheet |
QDSHS-09 | 43 m3, 28T | 3 | 7.6 m | Galvanized sheet |
Material description: | ||||
2. Pan feeding line system
In the pan feeding system the feed sensor control the motor to open and close to realize the automatic feeding. The system consists of hopper, motor, feed pipe and auger.
Name | Description |
Pan feeder | 1. By sliding shutter can adjust feed amount from complete open to complete close. |
Hopper | Capacity: 100L, raw material is hot galvanized steel, coat 120g/ m2 |
Auger | Imported from South Africa, feed capacity is 450kg/h. |
Delivery pipe | 4 pans/3m, diameter: ø45mm |
3. Nipple drinking line system
In modern poultry production, nipple drinkers have been proven to be a reliable and hygienic solution for the supply of water. It is consisted by water front parts, drinking system, hanging system, regulator and water line end parts .
Name | Description |
Nipple shell | Made of high-quality engineering plastic, and the valve rod inside is made of high-quality stainless steel. |
Valve stem | Can rotate freely at 360 degree to meet bird water demand of different period |
Hanging system | It is easy to adjust the height and the levelness by the winch and the adjustable strip |
Structure | Double-decked seal structure can effectively avoid wasting water and the resulting impact on the environment humidity. |
Feeding capacity | broiler: 8-12 birds /nipple, birds in cage: 12 birds/nipple, breeder: 10 birds/nipple |
Dosing device | Flow rate: 10 L / h - 2.5 m3/h |
Water Level Display Height:
Chicken Age (days) | 1-7 | 8-14 | More than 15 |
Water Level Height of Tube (mm) | 50-80 | 80-200 | 200-350 |
4. Ventilation& environment control system
a. This system is of great importance for a chicken house, which is used for providing a most suitable growing environment for chicken.
b. The system consists of below parts: air inlet, exhaust fan, cooling pad, spraying system and panel door.
c. Cooling pad and exhaust fan combination is the most economical and effective method to lower the temperature in summer.
Exhaust fan component list:
Name | Feature |
Motor | High efficiency and low wastage of energy. The Grade of protection is IP54 and the Insulation Grade is F. Rated power: 1.1kw, rated voltage: 380v |
Frame | Galvanized steel sheet, steel thickness 275g/m2,stamping forming, bottom outlet. |
Blade | Stainless steel blade, By dynamic balance test machine, stable running and volume stability. |
Shutters | Hot galvanized sheet forming, with automatic opening device |
Defend net | Hot galvanized anti-rust processing. |
Automatic opening device | Nylon and glass fiber materials, long life service. |
Belt | Imported from Japan, long-term use without deformation. |
Belt pulley | Hard alloy material quality by hot die casting, light material and high intensity. |
5. Cooling pad system
1) Corrugated paper with the spatial crossing linking technology, high absorbability, high water resistant, anti-mildew and long service life.
2) Thickness: 0.1m, 0.15m; Width: 0.6m; Height: 1.5m, 1.8m, 2m, also can produce according to the requirements of clients.
3) Large evaporation area, cooling efficiency is up to 80%.
4) No surfactant or harmful chemicals, like phenol.
5) Frame: aluminum alloy and PVC ,good appearance and long serve time;
6) The product absorbs water naturally, with fast speed of pervasion and lasting effectiveness. One drop of water can diffuse within 4~5 seconds. The natural absorption height is 60~70mm/5minutes, as 200mm/1.5 hours, having reached international standard.
7) The pump with the filter can supply clean cycle water
7) Detachable cooling pads as the choice.
8) The cooling pads and ventilation fan combination is the most economical and effective to decrease the temperature in summer. Reasonably design and installed the cooling pads can control the
temperature in the poultry house to 30 degree centigrade.
6. Heating system hot-blast stove
1. Various fuels are applicable, e.g. used blast furnace gas,coke oven gas, mixed gas, producer gas,natural gas,liquefied petroleum gas, heavy oil, diesel oil and organic waste,etc.
2. Indoor hanging type, automatic running, low noise and powerful blowing;
3. Temperature-set system available.
4. Stainless steel heating-exchanger.
5. Computer controlling, remote controller enables worker to start and stop the machine from 20 meters away.
6. Exhausting air complies with the requirements of EURO III;
8. Heating adjustable by adjusting burner's output.
Seq. | Model | Heating area(m 2 ) | Power(kw/h) | Fuel | Size(L*W*H) | Weight(kg) |
1 | SCF20 | 800 － 1000 | 4.95 | coal | 2200*900*1500 | 1700 |
2 | SCF30 | 1000 － 1300 | 6.75 | 2400*1000*1700 | 2100 | |
3 | SCF40 | 1400 － 1800 | 8.75 | 2600*1100*1800 | 2450 | |
4 | SDF05 | 300 | 1.25 | diesel | 1200*850*1000 | 280 |
5 | SDF10 | 600 | 2.35 | 1500*950*1100 | 320 | |
6 | SDF20 | 1200 | 4.55 | 1700*1100*1150 | 500 |
Excellent value service we provide
1. Poultry house site selection.
2. Poultry house design and construction, supply steel structure material.
3. Poultry equipment installation.
4. Free technical guidance and good after-sale service.
